Modular System for In-Field Swaps

Be ready for anything — Need an accurate DSM followed up by a multispectral survey? With Marlyn’s quick swap camara system you’re ready in minutes.

Sony A7C

A brand-new RGB surveying sensor with big capabilities and a small price tag! Equipped with Sony's 24MPx Full-Frame Sensor, this package will provide images as sharp as 1.7cm GSD without breaking the bank (€19,700 PPK-Ready Bundle).
1.70
24.2
Lowest GSD
Megapixel

Sensor layout Full Frame

Spectral bands RGB

Sensor size 35.9 x 24 mm

Shutter type Leaf shutter

Pixels array 6000 x 4000 px

No items found.
No items found.
No items found.
No items found.

Performance Calculator.

6000
4000
35.9
25
60
75
Ultra high resolution = 1.2 cm/px
Ultra high resolution = 0.5 inch/px
1.2
30
Sony A7C
7952
5304
35.9
35
60
75
Ultra high resolution = 1 cm/px
Ultra high resolution = 0.4 inch/px
0.6
30
Sony RX1RII
1280
960
4.8
5.4
60
75
Ultra high resolution = 3.5 cm/px
Ultra high resolution = 1.4 inch/px
3.5
30
MicaSense RedEdge-MX
2064
1544
7.16
8
60
75
Ultra high resolution = 2.2 cm/px
Ultra high resolution = 0.9 inch/px
2.17
30
MicaSense Altum
m
m
cm/px
Ultra high resolution = 1cm/px
Calculate
Thank you! Your submission has been received!
Oops! Something went wrong while submitting the form.
Images captured:
0
Flight time (Mins):
0
Altitude (m):
0
Ultra high resolution = 1cm/px
Reset
(Calculations based on a 60% Sidelap)

Selected for Accuracy & Quality

Our sensor line-up represents the best possible sensors on offer for drone surveying. With integrated Septentrio PPK, this means you get the best possible accuracy each time you go out.

Thoroughly tested with 100’s of flight hours.

For true accuracy and absolute reliability, all of Marlyn's sensors are thoroughly tested in the field for a wide variety for use cases and situations. This means you get data that works for your project!

Ready for Future Upgrades

We believe in keeping our users current, so with Marlyn's modular payload arrangement when the time comes for future payloads, your Marlyn is ready to expand into new possibilities of surveying.

Frequently Asked
Questions

Do you provide custom sensor integrations?
Due to the requirements of a fixed-wing drone, it is not possible to quickly integrate custom sensors for single projects. However we always welcome the feedback of our users for new sensor integrations, so feel free to get in touch with your suggestions and we will be happy to investigate its feasability for current releases..
Can I use my existing Sony/Micasense sensor in my Marlyn?
If your existing sensor is either MicaSense Altum, MicaSense RedEdge-MX, or Sony RX1RII, or Sony A7C, you can purchase a 'sensor-ready' payload module at the cost of €1000 on top of the base price. Due to minor calibration differences between batches of each sensor, it is required to send your sensor to Atmos for integration into your unit to ensure the best accuracy results.
What is included with Marlyn’s bundle?
The main components are: Marlyn VTOL drone (ready to fly), Sensor including lens and accessories, Navigator planning and ground control software (+ unlimited updates), protective transportation backpack, Two sets of flight batteries and a dual battery charger, Radio modem to connect your laptop/tablet with Marlyn, Remote control, Training on how to fly Marlyn (max 4 persons, excluding travel expenses), user manual and in-field maintenance kit.
Are you planning to integrate different sensors in the future?
We continuously improve our platform through different R&D projects based on the feedback we get from the customers. Additional payloads, such as a LiDAR sensor or more cameras are currently in development (will be integrated in the future depending on the demand). Let us know if you have any specific preferences!
